Cutable LED Neon Rope Light IP68 14w/M Energy Saving And Eco Friendly

Brand Name : TL

Model Number : TL-SW08A/B

Certification : CE,ROSH,UL

Place of Origin : Shenzhen,China

MOQ : 1pcs

Price : Negotiable

Payment Terms : T/T

Supply Ability : 5000m/day

Delivery Time : 7-15 workdays

Packaging Details : Carton

Material : silicon

Standard length : 5 meters(16.4ft)/10m(32.8ft)

Beam angle : 150°

Input voltage : 12V/24V

Power : 14w/m

Color : white/red/green/blue/yellow /pink/purple

Waterproof : IP68

Performance : Stable reliability,UV and yellowish resistant

Lifetime : 50000H

certification : UL CE ROSH

Contact Now

Mini Size 8x10mm Silicone Led Neon Rope 2.5mm Cut-able with CE UL

Application

Can be Widely used in building outline decoration lighting, KTV decoration lighting, Car decoration lighting, urban lighting and others decoration lighting.

Product features

Product standard length: 5 meters(16.4ft).
Product can be fixed in the rugged place (smooth surface and bendable).
Beam angle: 150°.
Input voltage: 12VDC/24VDC.
Excellent lumen maintenance (3oz FPC).
12VDC product: maximum length 10 meters (32.8ft).
24VDC product: maximum length 15 meters (49.2ft).
Flexible cutting (the cut mouth sealed by silicone glue).
IP68.
table reliability and anti-UV.

Application data

Maximum length①	10/15 meters (32.8/49.2ft)
Ambient temperature range	-25 ~ +50 °C
The temperature of module top	65 °C
Storage temperature range	-40 ~ +70 °C
Certification	CE/UL/ RoHS

Installation

U-type PC accessory to fix

Technical data

Product Name	Nominal voltage③	Color temperature or Wavelength①②	CRI①②	Typ. Flux/meter(3.28ft) ①②	Typ. Power/meter(3.28ft)①②
TL-SW08A/B(2835)	12/24 VDC	2700-5500 K	>75	850~1100 lm	12 W
TL-SR08A/B(2835)	12/24 VDC	620-625 nm	Red	300~350 lm	12 W
TL-SG08A/B(2835)	12/24 VDC	520-528 nm	Green	210~230 lm	12 W
TL-SB08A/B(2835)	12/24 VDC	465-470 nm	Blue	1100~1010 lm	12 W
TL-SY08A/B(2835)	12/24 VDC	590-596 nm	Yellow	300~310 lm	12 W

① Tolerance range for optical and electrical data: ±15 %.

② All value @ ta=25℃.

③ Voltage tolerance range of the power supply: ±5 %.

Product 2D drawing

12VDC/24VDC product interior drawing

3 LEDs cut-able

6 LEDs cut-able

Cutable LED Neon Rope Light IP68 14w/M Energy Saving And Eco Friendly

Product installation schematic diagram

Cutable LED Neon Rope Light IP68 14w/M Energy Saving And Eco Friendly

Product sectional drawing

Cutable LED Neon Rope Light IP68 14w/M Energy Saving And Eco Friendly

Product application

Product ⇒ Fix letter groove ⇒ Clip product ⇒ Actual result

Cutable LED Neon Rope Light IP68 14w/M Energy Saving And Eco Friendly

Connect two products

Product ⇒ Cut the product based ⇒ Solder the wire ⇒ Actual result

on application requirement “+/+”, “-/-“

Cutable LED Neon Rope Light IP68 14w/M Energy Saving And Eco Friendly

Benging direction

The maximum bending angle 360°The minimum bending radius: 15mm (0.59")

Light distribution

Cutable LED Neon Rope Light IP68 14w/M Energy Saving And Eco Friendly

Packaging information

Product name

Product dimension

(L*W*H)

Carton dimension

(mm/inch)

Total length/carton

Gross

weight (kg)

RCC0GX06A/B(2835)

5m*8mm*12mm (16.4ft*0.32"*0.47")

520*370*260 (20.5"*14.5"*10.2")

200m (656ft)

Cutable LED Neon Rope Light IP68 14w/M Energy Saving And Eco Friendly
